mini PCIe Paralle Port Card

Model :
SLMA3020
Name:
mini PCIe Paralle Port Card

Description

The SLMA3020 Mini PCIe Parallel Port Card uses the PCIe interface standard for expansion bus, enabling this card to be installed on any embedded or micro system with Mini PCIe expansion capability. By using this card, end user can add parallel ports to the computer for connecting their I/O devices. The card offers superior performance and unmatched data transfer rates. It is also ideal for industrial automation applications.


Specification & Feature
  • Fully compliant with PCI-Express Base Specification Revision 1.1
  • Single-Lane (x1) PCI-Express with throughput up to 2.5Gbps
  • Compatible with PCI-E Mini Card Electromechanical specification revision 1.2
  • Compatible with Full-Mini (F1) card type form factor
  • IEEE 1284 compatible parallel port
  • Supports SPP, PS2, EPP and ECP mode operation
  • Fast data rates up to 1.5Mbps
  • Supports Windows 7 / Vista / XP / Server 2003-2008 32/64-bit, 2000, Linux, Mac OS/X 10.5, and DOS 6.22

mini PCIe Parallel Port Card

mini PCIe Parallel Port Card

mini PCIe Parallel Port Card

mini PCIe Parallel Port Card
