- Power Supply Breakout Board with Adjustable Voltage Knob and 3.3v/5v/12v /USB 2.0/QC 2.0/ 3.0/12v for HP/DELTA/ FUJITSU/LITEON brand PSU
- This power supply breakout board, with ADJ adjustable voltage knob, supports 3.3V, 5V, 12V and 1.8V-10.8V (ADJ) output voltage.
- 4 USB 2.0 ports design, supports QC 2.0/QC 3.0.
- The voltage output terminals correspond to each screw terminal.
- At the same time, the bottom panel is also equipped with an acrylic case kit for easy to use.
- Compatible with 3.3V: STM32 MCU, network communication equipment, such as Wi-Fi Bluetooth and other devices, generally for microcontrollers, and some low-power modules, etc. 5V: Raspberry Pi, Banana Pi, Tinker Board, Nano Pi, USB interface, etc.
- Compatible with 9V: Arduino, motor drive, display driver module, etc. 12V: motor drive, LED light, vehicle equipment with power requirements less than 24w, etc.
- This adapter is only suitable for the following model of power supply:DPS-800GB A, DPS-1200FB A, DPS-1200QB A, PS-2751-5Q, PS-2751-LF-1F, HSTSN-PL12, DPS-700LB D, PS-2112-5L, DPS-750RB A, FUJITSU brand: DPS-800GB-5A/ DPS-800GB-3A
|
